MTB hubs come in a wide variety of dimensions and types to fit multiple bike/fork/axle standards and to suit different off-road disciplines.

Aside from the obvious decision – front or rear? - there are a number of things to take into account when choosing a new hub or hubset, among them bearing type, materials, disc mount standard, axle type and rims.

Bearing Type

Good-quality bearings, sealed and protected from dirt and water, are the key to long and healthy hubs. Older or less expensive hubs may use cup and cone bearings, which contain two rings of loose ball bearings that sit in 'cups' inside the hub body, and are secured in place by conical nuts known as 'cones'. The balls can rotate freely between the cup and cone with each unit making up one bearing.

Cup and cone bearings have the advantage of being easily serviced at home – new bearings and a dollop of grease once in a while are all you need to keep them running smoothly – but they can be tricky to adjust perfectly. More expensive hubs may use cartridge bearings, where the steel balls or needles rotate in a single cartridge unit that can be easily removed for servicing or replaced once worn out. Many riders prefer the convenience of cartridge bearings – no more tedious micro-adjusting or hunting for stray ball bearings mid-service – but they are more expensive to replace.

Materials

Most MTB hubs, front and rear, will be made of lightweight aluminium alloy although carbon fiber units are available at the top end of the market. Rear hubs for trail, jump and gravity bikes may use steel rather than aluminium freewheels to prevent the softer alloy splines being chewed up by the cassette under heavy load.

Brake Rotor Compatibility

Bikes running disc brake systems need hubs to which the disc rotor can attach. There are two main standards for rotor mounting, six-bolt and Centrelock. As the name suggests, six-bolt systems have hubs with six evenly-spaced holes to bolt on a matching rotor. Rotor bolts generally use Torx heads so you will need to make sure you have a Torx tool to tighten or loosen them – don’t try to fudge the job with an Allen key or you will risk stripping the bolts.

The Centrelock system used by Shimano foregoes rotor bolts in favor of a splinted hub-rotor interface secured with a locking ring (special tool needed). This is claimed to reduce installation time but it does put limits on mixing and matching hubs and brakes as most other manufacturers stick with the six-bolt system. Again

however, adapters are available to mount six-bolt rotors to Centrelock hubs, and vice-versa. Before investing in new hubs check which disc interface you are currently using and buy accordingly.

Axle Size (Front)

You must also ensure that your hubs are compatible with your fork axle. Many entry-level or shorter-travel cross-country forks attach to the hubs via quick-release (QR) skewers, with a 9mm diameter axle clamped into the fork and frame dropouts via a 5mm QR skewer. However recent years have seen the growth of the 'bolt-through' or 'thru-axle' standard on MTB front forks for trail, enduro and gravity riders. This uses a larger-diameter (12mm, 15mm or 20mm) axle for extra stiffness and security, with the axle threading right through the fork ends and being secured by two QR clamps integrated into the fork lowers.

If you intend to upgrade your wheels make sure the hubs match whichever axle standard you are using, or alternatively consider hubs that can switch between QR and bolt-through with the insertion of a simple adaptor to enable the wheels to be used with different fork types.

Axle Size (Rear)

Rear hubs are sized according to the diameter and length of the rear axle (measured in millimetres). The standard MTB rear axle dimensions are 135x5mm (for a QR rear hub) but jump and gravity bikes may use wider and thick axles for extra strength and stiffness, with the available sizes being 135x10, 142x12, 150x12, 157x12 and 165x12. Ensure your rear hub is the correct size to fit your frame.

Rims

If choosing a new hub to rebuild a wheelset you will need to match the number and type of spoke holes

on the hub's flange to the number and type of spoke holds drilled into the rim, e.g. a 32h hub is designed for a 32-spoke wheel, and needs to be matched to a 32hole rim.
